Artikelnr: 6921538000055

Description:

Product features:

• Standard with mounting holes for zero point clamping system, Pitch 200
• The centre is adjustable. The position of the workpiece stays within set boundaries
• Repeating accuracy ± 0,01 mm for rectangular workpieces
• Guides ground, polished and paired
• Clamping range presetting via adjustment of clamping jaws along transverse slots of spindle nuts
• Moulding and clamping in a single step, directly in the work area – no auxiliary aids required
• Use with a torque wrench – max. 70 Nm
• Fully enclosed and maintenance-free high-pressure spindle – high chip protection, minimum cleaning requirements, constant clamping forces up to 40 kN
• Fixing via the hole grid on both sides or alternative with side clamps
• Horizontal installation – suitable for vertical CNC-controlled milling machines
• Ideal for use on 5-axis machining centres due to its compact design
• Depending on the clamping jaws, both pre-machined workpieces and unmachined parts can be clamped
• With support jaws, unmachined parts with varying types of flame cut and sawn materials and even complex castings can be clamped safely and economically. Gripp-studs suitable for materials of mechanical strength of up to approx. 1000 N/mm²

Scope of Supply:

• 1x high-pressure vice without jaws
• 2x combination wrenches
• 6x fastening screws, M12 x 35 mm
• 2x socket screw wrenches
• 1x wrench socket
• (Please order clamping jaws separately)
