Allmatic
Artikelnr: 6921684020042
Description:
- Material: hardened steel
- Case-hardened and tempered 680 + 80 HV30; hardening depth 0,5 + 0,3
- One side smooth, ground and polished; one side serrated
- Rotatable through 360°
- Click system on the high side
- Picture with hard base jaw (see order no. 6921684005731)
Scope of Supply:
- 1x Pivot jaw, movable
- 2x Cylinder head screws DIN 912 M12x45
-
Specifikation
Dimension, a 62 Dimension, b 124.4 Dimension, c 24 Dimension, h 39.5 Dimension, l 84
