Allmatic
Artikelnr: 6921274011231
Description:
- Material: hardened steel
- Case-hardened and tempered 680 + 80 HV30; hardening depth 0.5 + 0.3
- Additional thread for mounting HD jaws
- Ground and polished clamping surfaces
- Click system on the high side
Scope of Supply:
- 2x cylinder head screws DIN 912 M10x16
- 2x cylinder head screws DIN 912 M10x50
-
Specifikation
Dimension, a 56 Dimension, b 90 Dimension, c 20 Dimension, d 16 Dimension, h 46 Dimension, l 66 Dimension, l` 30
