Allmatic
Artikelnr: 6921294011231
Description:
- Material: hardened steel
- Case-hardened and tempered 680 + 80 HV30; hardening depth 0,5 + 0,3
- Additional thread for mounting hd jaws
- Ground and polished clamping surfaces
Scope of Supply:
- 1x Master jaw adapter movable
- 2x Cylinder head screws DIN 912 M16x30
- 2x Cylinder head screws DIN 912 M16x90
-
Specifikation
Dimension, a 89 Dimension, b 202 Dimension, c 30 Dimension, d 24 Dimension, h 85 Dimension, l 100 Dimension, l` 34
